Panasonic Aquarea L All in One Air-to-Water Heat Pump, 7.0 kW, R290, WH-ADC0509L3E5 / WH-WDG07LE5
Aquarea Alta Performance, All in One, L series single phase
A revolution in design, efficiency, connectivity and sustainability.
Aquarea Generation L has been designed with the natural refrigerant R290, with a GWP of 3. It is the perfect solution for renovations where a high water flow temperature is required or for homes where you want to install a cutting-edge heat pump with natural refrigerant.
Unrivalled energy efficiency and consumption reduction with limited CO2 emissions and minimal space requirement.
A premium white, true to the Aquarea spirit, highlighted by the perfectly integrated control panel featuring an elegant black band along the unit.
The All in One model maintains its compactness with a footprint of 599 x 602 mm, comparable to a household appliance.
The anthracite gray outdoor units, which characterize the entire range, have been completely redesigned with an innovative design that adapts to any space.
- Natural refrigerant R290 with GWP equal to 3
- A+++ in heating mode at 35°C and A+ in DHW
- ACS up to 65°C without resistance
- Stainless steel hot water tank with U-Vacua™ insulation panel
- ACS COP up to 3.60
- Hydraulic connection between inside and outside
- Built-in magnetic water filter
- Operation without reserve resistance at -25 °C
- Water flow temperature 75°C maximum at -10°C outside temperature
- Hot water at 55°C even with an outside temperature of -25°C
- Optimized user interface and improved functions
- Wi-Fi adapter included
L -series
- Ideal choice for modernization projects, installation in renovated buildings with an existing radiator system
- With natural refrigerant R290
- Hydraulic connection of indoor and outdoor equipment
- Provides up to 75°C water outlet temperature at -10°C
- Up to 65°C domestic hot water supply without tank sterilization heater
- Improved design with a new indoor unit designed to perfectly complement your home, as well as a renewed, architecturally appealing outdoor unit in anthracite grey
- Seamless connectivity integration with the option to integrate your Wi-Fi module into the indoor unit
Specifications
| Aquarea Alta Performance, All in One, L series, single phase, R290 | |||
|---|---|---|---|
| 7 kW | |||
| Heating capacity (A +7°C, W 35°C) | kW | 7.00 | |
| COP (A +7°C, W 35°C) | 4.93 | ||
| Heating capacity (A +7°C, W 55°C) | kW | 7.00 | |
| COP (A +7°C, W 55°C) | 2.98 | ||
| Heating capacity (A +2°C, W 35°C) | kW | 6.85 | |
| COP (A +2°C, W 35°C) | 3.43 | ||
| Heating capacity (A +2°C, W 55°C) | kW | 6.25 | |
| COP (A +2°C, W 55°C) | 2.34 | ||
| Heating capacity (A -7°C, W 35°C) | kW | 5.80 | |
| COP (A -7°C, W 35°C) | 3.01 | ||
| Heating capacity (A -7°C, W 55°C) | kW | 5.80 | |
| COP (A -7°C, W 55°C) | 2.12 | ||
| Cooling capacity (A 35°C, W 7°C) | kW | 7.00 | |
| EER (At 35°C, W 7°C) | 3.03 | ||
| Cooling capacity (A 35°C, W 18°C) | kW | 7.00 | |
| EER (At 35°C, W 18°C) | 4.73 | ||
| Seasonal Energy Efficiency - Average Climate (W 35°C / W 55°C) | SCOP | 4.96 / 3.62 | |
| Seasonal Energy Efficiency - Average Climate (W 35°C / W 55°C) | ηs % | 195 / 142 | |
| Energy efficiency class average climate (W 35°C / W 55°C) (1) | A+++ to D | A+++ / A++ | |
| Seasonal energy efficiency. Warm climate (W 35°C / W 55°C) | SCOP | 6.31 / 4.52 | |
| Seasonal energy efficiency. Warm climate (W 35°C / W 55°C) | ηs % | 249 / 178 | |
| Energy efficiency class. Warm climate (W 35°C / W 55°C) (1) | A+++ to D | A+++ / A+++ | |
| Seasonal Energy Efficiency - Cold Climate (W 35°C / W 55°C) | SCOP | 4.25 / 3.29 | |
| Seasonal Energy Efficiency - Cold Climate (W 35°C / W 55°C) | ηs % | 167 / 129 | |
| Energy efficiency class. Cold climate (W 35°C / W 55°C) (1) | A+++ to D | A++ / A++ | |
| Internal sound pressure (Risc) | dB(A) | 28 | |
| Internal sound pressure (Raff) | dB(A) | 28 | |
| Class A Pump (Number of Speeds) | Variable Speed | ||
| Class A pump (Min. input power) | W | 30 | |
| Class A pump (Max. input power) | W | 145 | |
| Nominal power in heating (∆T=5 K. 35°C) | L/min | 20.1 | |
| Water volume | THE | 185 | |
| Maximum water temperature | °C | 65 | |
| Tank material | Stainless steel | ||
| Load profile according to EN 16147 | THE | ||
| Effect class energy for production ACS - average climate | A+ to F | A+ | |
| Effect class energy for production ACS - warm climate | A+ to F | A+ | |
| Effect class energy for production ACS - cold climate | TO | ||
| DHW tank ERP average climate η | ηwh % | 146 | |
| DHW tank ERP warm climate η | ηwh % | 160 | |
| DHW tank ERP cold climate η | ηwh % | 112 | |
| External unit | WH-WDG07LE5 | ||
| Outdoor unit dimensions (Height) | mm | 996 | |
| Outdoor unit dimensions (Width) | mm | 980 | |
| Outdoor unit dimensions (Depth) | mm | 430 | |
| Operation range - Outdoor ambient (Heat) | °C | -25 ~ +35 | |
| Operation range - Outdoor ambient (Cool) | °C | +10 ~ +43 | |
| Water delivery temperature (Heating) | °C | 20 ~ 75 | |
| Water flow temp. (Cooling) | °C | 5 ~ 20 | |
(1) Scale from A+++ to D.
(2) Scale from A+ to F.
(3) Sound power level is measured in accordance with EN12102 under the conditions of EN14825 (partial load).
(4) Check local regulations.
* EER and COP calculation is defined in accordance with EN14511.
** This product is designed to comply with the European Water Quality Directive 98/83/EC, as amended by Directive 2015/1787/EU. The product lifespan is not guaranteed when using groundwater, such as spring or well water, tap water containing salt or other impurities, or in areas with acidic water. Maintenance and warranty costs arising from such conditions are the responsibility of the customer.
(2) Scale from A+ to F.
(3) Sound power level is measured in accordance with EN12102 under the conditions of EN14825 (partial load).
(4) Check local regulations.
* EER and COP calculation is defined in accordance with EN14511.
** This product is designed to comply with the European Water Quality Directive 98/83/EC, as amended by Directive 2015/1787/EU. The product lifespan is not guaranteed when using groundwater, such as spring or well water, tap water containing salt or other impurities, or in areas with acidic water. Maintenance and warranty costs arising from such conditions are the responsibility of the customer.
