HERZ DE LUXE VUA-50 M22 Design Radiator Connection for Two-Pipe Systems, Angle, Chrome, S768441

HERZ DE LUXE VUA-50 S768441 is a chrome-plated angle four-way radiator valve for two-pipe heating systems, designed for radiator connection and thermostatic flow control.

The valve incorporates a HERZ TS-98-V continuously presettable thermostatic insert in the return, allowing precise hydraulic adjustment of radiator flow.

The two-pipe version is designed without a bypass. The supply side can be shut off and the return can be isolated through the TS valve.

The radiator connection incorporates an immersion tube 290 mm long and 11 mm in diameter.

The thermostatic head connection is M28 × 1.5, suitable for compatible HERZ thermostatic heads including DE LUXE design versions.

The radiator connection is G1/2, while connection to the radiator is made by a freely rotating G3/4 union nut.

Pipe connections are M22 × 1.5 with cone, designed for compatible HERZ compression fittings.

The pipe centre distance is 50 mm. The angle configuration is suitable for installations where the heating pipes approach the radiator according to an angled connection arrangement.

HERZ DE LUXE VUA-50 S768441 combines a chrome design finish, compact angle configuration, thermostatic control and hydraulic presetting for two-pipe radiator systems.
