Mitsubishi Electric ECODAN ERSD-VM2D / SUZ-SWM80VA (230V, 1F) heat pump 7.5kW

6933.30 EUR  5750.00 EUR

Datu lapa

Add to cart

Mitsubishi Electric ECODAN ERSD-VM2D / SUZ-SWM80VA is an air-to-water heat pump system with a Hydrobox indoor unit and SUZ-SWM80VA outdoor unit, designed for efficient home heating, cooling and domestic hot water preparation with a separate hot water cylinder.

This model is suitable for private houses, terraced houses, new-build projects and renovation projects where a compact, energy-efficient and professional heating solution without an integrated domestic hot water tank is required. The Hydrobox indoor unit offers flexible installation options, as the hot water cylinder can be selected separately according to the needs of the building.

Mitsubishi Electric ECODAN ERSD-VM2D / SUZ-SWM80VA uses R32 refrigerant and is designed to operate in heating mode down to an outdoor temperature of -20 °C. The SUZ-SWM80VA outdoor unit has a 7.5 kW heating capacity, COP 4.70 and a maximum flow water temperature of up to 60 °C.

The heat pump is suitable for connection to underfloor heating, radiators, fan coil units and a domestic hot water system with a separate cylinder.

Main advantages

Efficient air-to-water heat pump for heating and domestic hot water preparation
Hydrobox indoor unit without integrated hot water cylinder
Suitable for use with a separate domestic hot water tank
Heating capacity 7.5 kW
High efficiency — COP 4.70
R32 refrigerant
230 V single-phase connection
Maximum flow water temperature up to 60 °C
Heating operation down to -20 °C outdoor temperature
Compact wall-mounted indoor unit
Suitable for underfloor heating, radiators and fan coil units
Professional Mitsubishi Electric ECODAN heating system solution

Technical information

Manufacturer: Mitsubishi Electric
Series: ECODAN
Set: ERSD-VM2D / SUZ-SWM80VA
Indoor unit: ERSD-VM2D Hydrobox
Outdoor unit: SUZ-SWM80VA
Product type: air-to-water heat pump
System type: split heat pump system
Application: heating, cooling, domestic hot water preparation with a separate tank
Integrated domestic hot water cylinder: no
Power supply: 230 V / 1 phase / 50 Hz
Heating capacity: 7.5 kW
COP in heating mode: 4.70
Cooling capacity: 6.5 kW
COP in cooling mode: 3.40
Maximum flow water temperature: 60 °C
Refrigerant: R32
Outdoor unit sound level: 62 dB(A)
Indoor unit sound level: 41 dB(A)
Additional electric heater: 2 kW
Control: LCD display
Energy efficiency class, low temperature 35 °C: A+++
Energy efficiency class, medium temperature 55 °C: A++
Seasonal efficiency 35 °C, average climate: 182 %
Seasonal efficiency 55 °C, average climate: 131 %
Maximum current: 13.9 A
Recommended circuit breaker: 16 A
Refrigerant pipe, liquid line: 6.35 mm / 1/4"
Refrigerant pipe, gas line: 12.7 mm / 1/2"
Pipe length: 5–30 m
Maximum height difference: 30 m
Operating range for heating: from -20 °C to +24 °C
Operating range for cooling: from +10 °C to +46 °C
Indoor unit dimensions: 530 × 800 × 360 mm
Outdoor unit dimensions: 840 × 880 × 330 mm
Indoor unit weight: 44 kg
Outdoor unit weight: 54 kg
Package dimensions: to be confirmed according to warehouse / supplier data
Gross weight: to be confirmed according to warehouse / supplier data
Delivery type: courier or freight delivery
Suitable for parcel locker: no
